VCO-SM75
PN | Frequency | Tuning Voltage | Tuning Sensitivity | Pout | Phase Noises | Vdd/l | Datasheet |
(MHz) | （V） | (MHz/V) | (dBm) | dBc/Hz@ 100kHz | (V/mA) | ||
VMVO90M100M-5SM75 | 90～100 | 0.5～4.5 | 3.5 | 5 | -135 | 5/13 | Request |
VMVO240M280M-5SM75 | 240～280 | 0.5～4.5 | 12 | 6 | -133 | 5/18 | Request |
VMVO270M356M-5SM75 | 270～356 | 0.5～4.5 | 24 | 3 | -130 | 5/16 | Request |
VMVO350M380M-5SM75 | 350～380 | 0.5～4.5 | 7.5 | 4 | -132 | 5/16 | Request |
VMVO370M390M-5SM75 | 370～390 | 0.5～4.5 | 8 | 3 | -132 | 5/16 | Request |
VMVO410M460M-5SM75 | 410～460 | 0.5～4.5 | 14 | 2 | -127 | 5/15 | Request |
VMVO640M820M-5SM75 | 640～820 | 0.5～4.5 | 45 | 5 | -120 | 5/30 | Request |
VMVO900M01G6-5SM75 | 900～1600 | 0.5～4.5 | 190 | 4 | -118 | 5/30 | Request |
VMVO01G502G1-5SM75 | 1500～2000 | 0.5～4.5 | 160 | 0 | -107 | 5/15 | Request |
VMVO01G702G1-5SM75 | 1600～2165 | 0.5～4.5 | 140 | 0 | -108 | 5/31 | Request |
VMVO01G702G1-5SM75 | 1700～2150 | 0.5～4.5 | 140 | 0 | -112 | 5/28 | Request |
VMVO01G802G2-5SM75 | 1800～2200 | 0.5～4.5 | 110 | 4 | -114 | 5/26 | Request |
VMVO01G902G5-5SM75 | 1900～2500 | 0.5～4.5 | 160 | 0 | -104 | 5/28 | Request |
VMVO02G302G7-5SM75 | 2300～2700 | 0.5～4.5 | 140 | -2 | -112 | 5/18 | Request |
VMVO02G603G1-5SM75 | 2600～3100 | 0.5～4.5 | 140 | -1 | -112 | 5/18 | Request |
VMVO03G103G7-5SM75 | 3100～3700 | 0.5～4.5 | 180 | -1 | -105 | 5/18 | Request |
VMVO640M820M-5SM75 | 640～820 | 0.5～4.5 | 45 | 5 | -120 | 5/30 | Request |
VMVO02G903G5-5SM75 | 2900～3500 | 0～12 | 70 | 5 | -92 | 5/23 | Request |
VMVO03G504G3-5SM75 | 3500～4300 | 0～12 | 130 | 5 | -90 | 5/23 | Request |
VMVO04G505G1-5SM75 | 4500～5100 | 0～12 | 140 | 2 | -90 | 5/23 | Request |
VMVO04G705G4-5SM75 | 4700～5400 | 0～12 | 100 | 0 | -88 | 5/23 | Request |
VMVO05G506G1-5SM75 | 5550～6100 | 0～12 | 75 | 0 | -90 | 5/20 | Request |
